Optilab’s DFB-1064-PM-M-100 is a Distributed Feedback (DFB) Polarization Maintaining (PM) laser source module designed for integration with an optical modulator to form a high bandwidth analog or digital photonics link. With the DFB laser’s operating temperature and output power precisely controlled to ensure constant wavelength and power stability. The DFB-1064-PM-M-100 is designed to work with the Optilab Compact Modulator w/ Bias Control (CMB) for RFoF applications. Utilizing the USB / RS-485 port, the user can control the laser drive current and wavelength via PC interface.

Features:
➤ Polarization Maintaining (PM) Output
➤ Laser Linewidth 100 KHz
➤ Relative Intensity Noise (RIN) of -145 dB/Hz
➤ Up to 100 mW Output

Applications:
➤ Light Source 40 G RFoF Analog Link
➤ External Modulated DWDM Networks
➤ Seed Oscillator Laser for MOPA
➤ Laboratory Testing and Measurement
➤ HFC Fiber Link

Datasheet
