The Optilab YDFA-40-R is a high-gain three staged single mode optical amplifier unit designed for applications requiring high efficiency optical amplification in the 1060 nm regime in both CW and pulse mode operations. It is a selfcontained, turn-key standard 1U rackmount designed to supply high and stable gain across the specified range of the wavelength window with optical output power up to +40 dBm.

Features:

• High SNR near saturation power • Saturation power Up to +40 dBm • Triple Staged Amplification • Pulse and CW operation modes • Interlock safety feature • Gain up to 40 dB

Applications:

• SHG • Medical • Industrial • Fiber Optic Sensing • Lower Power Pulse Amplification • MOPA
